Citing this page: IMGT/LIGM-DB: IMGT000061 (157118 bp), Arabian camel (Camelus dromedarius) IGK locus on the chromosome 28.

Arabian camel (Camelus dromedarius) IGK locus on chromosome 28

The orientation of the Arabian camel (Camelus dromedarius) IGK locus on the chromosome 28 is forward (FWD).

Locus representation arabian_camel IGK

Legend:
Colors are according to IMGT color menu for genes.
The boxes representing the genes are not to scale. Exons are not shown.
A double slash // indicates a gap in genome assembly. Distances in bp (base pair) or in kb (kilobase) associated with a double slash are taken into account in the length of the lines and included in the numbers displayed at the right end of the lines.
A dotted line ... indicates the distance in kb (kilobase) between the locus and its bornes (5' borne and the most 5' gene in the locus and/or 3' borne and the most 3' gene in the locus) on the top and bottom lines, respectively. These distances are not represented at scale and are not included in the numbers displayed at the right ends of these two lines.

IGK gene names are according to the IMGT nomenclature [1].
Single arrows show genes whose polarity is opposite to that of the J-C-CLUSTER comprising IGKJ1 to IGKC.

Gene names of IGKV pseudogenes with frameshift(s) in the V-REGION are not displayed due to a lack of space in the locus map at the IMGT standardized scale (line = 200 kb). For all gene names, see Zoom x2.

Zoom for IGK V-J-C-CLUSTER

zoom

Zoom for IGK J-C-CLUSTER

zoom

IMGT references:
  1. [1] Lefranc M-P. Front Immunol. 2014 Feb 05;5:22. doi: 10.3389/fimmu.2014.00022. Open access.. PMID: 24600447
