IMGT Repertoire (IG and TR)


Locus representation: western lowland gorilla (Gorilla gorilla gorilla) IGK locus on chromosome 2A assembly NHGRI_mGorGor1-v1.1-0.2.freeze_pat

Citing this page: IMGT/LIGM-DB: BK063602 (893572 bp), western lowland gorilla (Gorilla gorilla gorilla) IGK locus on the chromosome 2A.

Western lowland gorilla (Gorilla gorilla gorilla) IGK locus on chromosome 2A assembly NHGRI_mGorGor1-v1.1-0.2.freeze_pat

The orientation of the western lowland gorilla (Gorilla gorilla gorilla) IGK locus on chromosome 2A assembly NHGRI_mGorGor1-v1.1-0.2.freeze_pat is reverse (REV).

Locus representation western lowland gorilla (<em>Gorilla gorilla gorilla</em>) IGK locus on chromosome 2A assembly NHGRI_mGorGor1-v1.1-0.2.freeze_pat

Legend:
Colors are according to IMGT color menu for genes.
The boxes representing the genes are not to scale. Exons are not shown.
A double slash // indicates a gap in genome assembly. Distances in bp (base pair) or in kb (kilobase) associated with a double slash are taken into account in the length of the lines and included in the numbers displayed at the right end of the lines.

IGK gene names are according to the IMGT nomenclature [1].

Zoom for J-C-CLUSTER

zoom

IMGT references:
  1. [1] Lefranc, M.-P. Front Immunol. 2014 Feb 05;5:22. doi: 10.3389/fimmu.2014.00022. Open access.. PMID:24600447
  2. [2] Lefranc, M.-P. and Lefranc, G., Academic Press, London, 458 pages (2001), The immunoglobulin FactsBook. 012441351X..
  3. [3] Lefranc, M.-P., Exp Clin Immunogenet., 18, 161-174 (2001)..
  4. [4] Ermert, K. et al., GENOMICS., 25, 623-629 (1995)..
  5. [5] Pargent, W. et al., Eur. J. Immunol., 21, 1821-1827 (1991)..
  6. [6] Lautner-Rieske, A. et al., Eur. J. Immunol., 22, 1023-1029 (1992)..
  7. [7] Hüber, C. et al., Eur. J. Immunol., 23, 2860-2967 (1993)..
  8. [8] Weichhold, G.M. et al., GENOMICS., 16, 503-511 (1993)..
  9. [9] Brensing-Küppers, J. et al., Gene., 191, 173-181 (1997)..
Created:
28/04/2022
Last updated:
06/08/2024
Authors:
Chahrazed Debbagh
